Main performance and structural features:

1. Motor drive, automatic centering of sealing machine (only available for CS models)< br /> 2. Automatic output technology function, total output setting function< br /> 3. Automatic sealing and cutting, automatic detection of products and detection of product length< br /> 4. Color touch screen, PLC operating system< br /> 5. Applicable shrink film: PE, PF folded film 10-50 μ Thick< br />

6. Conforming to EC CE standards.

Main performance and structural features:

1. The hot air circulation system adopts the integrated design, and the heating speed is fast< br /> 2. Solid state relay and PID control are adopted, and the temperature tolerance is ± 1 degree< br /> 3. The metal heating tube is adopted, which is durable< br /> 4. The heater adopts a unique drawer design to facilitate the inspection and replacement of the heating pipe< br /> 5. The dual-frequency governor controls the transmission speed< br /> 6. Baoxing movable simplified, high-temperature resistant rubber sleeve< br /> 7. The dual-frequency governor controls the blower to control the blower speed, and the blower flow can be adjusted according to the product< br /> 8. The blowing direction on both sides can be adjusted to achieve the expected contraction effect of the product< br />

9. 100mm thick thermal insulation layer can effectively reduce heat loss, that is, save electricity.

Main technical parameters:

Project model	ST-800
Power supply/power	200-240V，1ph-npe，50/60hz/3000W
Compressed air/air consumption	6bar，90L/min
Maximum sealing and cutting size	eight hundred and sixty × 670mm
Maximum packaging height	250mm for center seal 150mm for no center seal
Conveyor speed	10-30M/min
Average capacity/hour	40 bags/hour
Maximum roll width diameter	w800- φ 300mm
Machine size	two thousand five hundred and eighty × one thousand eight hundred and forty × 1620mm
Package size	two thousand four hundred and sixty-nine × one thousand seven hundred and forty × 1340mm
Machine weight	NW:750KG
