STZ-120

Multi-bag biscuit plastic cartoning machine

Product Overview：Multi-bag biscuit plastic cartoning machine belongs to non-standard customized equipment. The equipment automatically manages and counts materials, and automatically transports 12 bags of bagged food to the feeding silo. The cartoning machine breaks the traditional carton packaging method and uses transparent plastic boxes to seal the boxes, improving the beauty of the products. Due to the large size of the box, the plastic box is sealed by spraying glue. If the size of the box is small, the tongue type sealing method can be used.

Contact Send

Video

Technical parameter

Multi-bag biscuit plastic cartoning machine belongs to non-standard customized equipment. The equipment automatically manages and counts materials, and automatically transports 12 bags of bagged food to the feeding silo. The cartoning machine breaks the traditional carton packaging method and uses transparent plastic boxes to seal the boxes, improving the beauty of the products. Due to the large size of the box, the plastic box is sealed by spraying glue. If the size of the box is small, the tongue type sealing method can be used.

塑料盒封盒机塑料盒装盒机

技术参数：

model	STZ-120 cartoning machine
Paper requirements	280-350g/m2 (depending on the size of the carton)
Package specification	L65-200 × W35-120 × H20-120mm
Packaging speed	30-60 boxes/min
Folding machine speed	30-60 boxes/min
Paper requirements of instructions	55-65g/m2
Specification of instruction paper	Max=260x190mm； min=100x100mm
Main engine motor power	2kw
Total power	2kw (actual deviation)
Power supply type	380V 50HZ/60HZ three-phase five-wire
Machine noise	≦80dB
Air source	0.5-0.8Mpa
Gas consumption	120-160L/min
Overall dimension	four thousand and two hundred × one thousand four hundred and thirty × 1740mm
Operating Weight	2000kg

STZ-120

Multi-bag biscuit plastic cartoning machine

技术参数：
