ST-140B

Full-automatic copy paper packaging machine

Product Overview：Full-automatic copy paper packaging machine is suitable for automatic paper packaging. The transmission is mainly driven by the main motor, and the sprocket, chain, pulley, connecting rod, gear, combined with the servo motor, planetary reducer, turbine reducer, high-pressure vacuum pump, inflatable shaft, cam splitter, sensor, encoder and other auxiliary functions are turned to realize a mechanical movement of function conversion, achieving stable packaging operation, high efficiency, and superior quality of processed products, The cylindrical packaging structure has many advantages such as simple and fast operation.

Contact Send

Video

Technical parameter

equipment	ST-140B Sydney paper roll packaging machine
Thickness of wrapping paper	0.03-0.05mm
Maximum outer diameter of wrapping paper	φ five hundred
Wrapping paper core diameter	75mm-78mm
Recommended paper film weight	17-26g
Product specification	L90-130mm ×φ 95- φ 130mm
Stable packaging speed	60-120rolls/min
Total motor power	6.8kw (actual deviation)
Power supply type	380V 50HZ/60HZ three-phase five-wire
Machine noise	≦80dB
Air source	0.5-0.8Mpa
Gas consumption	120-160L/min
Operating Weight	3500kg
